Circular Mini DIN Plugs
Plug Components for
Cable Termination
Ordering Information
For each Plug Assembly, the following components are needed: one plug insulator, one shield,
and adequate contacts.
Component
Type
Insulator
Shield Case
Contact
Description
3 Position Insulator
4 Position Insulator
5 Position Insulator
6 Position Insulator
7 Position Insulator
8 Position Insulator
Metal Shield Case
Option 1 Plating
Option 1 Plating
Option 2 Plating
Option 2 Plating
Option 3 Plating
Quantity
1
1
1
1
1
1
1
300 on Reel
15,000 on Reel
300 on Reel
15,000 on Reel
15,000 on Reel
Catalog No.
MDX-3PI
MDX-4PI
MDX-5PI
MDX-6PI
MDX-7PI
MDX-8PI
MDX-PZ
MDX-P-3A
MDX-P-15A
MDX-P-3B
MDX-P-15B
MDX-P-15D
Tool Ordering Information
The following tools are recommended for Mini Din Cable Plug Assembly.
One tool of each type is required.
Tool Type
Contact Crimp
Contact Insertion
Insulator Insertion
Shield Crimp
Description
Stripper-Crimper Machine
Complete, Includes Dies
Contact Crimp Hand Tool
Crimps using 300 Contact Reels
Combination Contact Insertion
and Insulator Insertion Tool
Contact Insertion Hand Tool
Fixture used with MDT-P28
Insulator Insertion Bench Mounted Tool
Insulator Insertion Hand Tool
Pneumatic Crimp Tool
Catalog No.
MDT-P25
MDT-P35
MDT-P41
MDT-P28
MDT-P29
MDT-P34
MDT-P30
MDT-P81
Overview of Assembly Steps
? Prepare multi-conductor cable.
? Crimp contacts onto individual conductors using tool MDT-P25 or tool MDT-P35.
? Insert contact with conductor into insulator using tool MDT-P41 or have insertion tool MDT-P28 with insulator locating
vice MDT-P29.
? Insert insulator into the shield case using tool MDT-P34 or MDT-P30.
? Crimp the shield case onto the cable shield using tool MDT-P81.
? Overmold plastic to complete the assembly.
Marketed exclusively through distribution.
2-61
